Maintenance Free Fiber Laser Marking Machine Eco Friendly Metal Engraving Equipment

Name: Maintenance Free Fiber Laser Marking Machine Eco Friendly Metal Engraving Equipment
Brand: Syscode
Price: 1299 USD

Maintenance Free Fiber Laser Marking Machine Eco Friendly Metal Engraving Equipment Manufactures

Brand Name : Syscode

Model Number : F200

Certification : CE

Place of Origin : China

MOQ : 1set

Price : 1299$~15999$

Payment Terms : L/C,T/T

Delivery Time : 2-3 work days

Packaging Details : Carton Box

Maximum Power Consumption : 400W

Fonts : Standard fonts in Chinese,English,numbers,traditional characters,etc.

Data Protection : Power-off data protection function

Missed Mark Detection : Provides overspeed alarm function duetomaterial reflectivity

Production LineSpeed : 0~130m/min(Dependenton material)

Number of Marking Rows : Any within themarkingrange

Positioning Method : Red Light Focusing

Marking Range : 110mm×110mm(Optional)

RepeatPositioning Accuracy : Red Light Focusing

Laser Wavelength : 1064nm

Laser Source : Fiber Laser Generatorwith aservice life of over 80,000 hours

Contact Now

Fiber Laser Coding Machine

The fiber laser marking machine is widely used in various industries, including electronic components, hardware tools, electrical products, consumer goods, sensors, automotive parts, 3C electronics, crafts, gifts and jewelry, high and low voltage electrical appliances, bathroom industry, battery industry, and the T industry.

Main Features

Wide Application Range: The device offers a high cost-performance ratio.
Maintenance-Free: The air-cooled laser requires no maintenance and does not need lens adjustments or cleaning, with an average working life of 80,000 to 100,000 hours.
Eco-Friendly: It produces no harmful substances during operation, complying with environmental standards and promoting sustainable development.
High Precision: Equipped with a red light positioning system for easy and accurate positioning.
Computer Programming: Automatic printing can be programmed to change content such as English, numbers, Chinese characters, and graphics at will.

Maintenance Free Fiber Laser Marking Machine Eco Friendly Metal Engraving Equipment
Technical Specifications:

Parameter	FL-30	FL-50	FL-100
Machine Material	Sandblasted Oxidized Aluminum Structure
Laser Source	Fiber Laser Generatorwith aservice life of over 80,000 hours
Laser Wavelength	1064nm
MarkingSpeed	≤12000mm/s
Main Control	10.2-inch Touch Controller
Cooling System	Air-cooled at room temperature
Focusing Lens	Optional,Focal Length165mm
Minimum Line Width	0.0012mm
RepeatPositioning Accuracy	0.003mm
Marking Range	110mm×110mm(Optional)
Positioning Method	Red Light Focusing
Number of Marking Rows	Any within themarkingrange
Production LineSpeed	0~130m/min(Dependenton material)
Languages	English,French,Spanish,German,Chinese,Russian,Arabic,etc.
User Management	Multipleuser management permissions
Operating System	Linux
Marking Modes	Static,Dynamic,Encoder
Reserved Signals	Startprinting,Printing status,Printing complete,Fault alarm
Data Protection	Power-off data protection function
Missed Mark Detection	Provides overspeed alarm function duetomaterial reflectivity
Cross Point Removal	Automatic removal ofcross points to avoid overlapping
Printing Software	Supports singleand doublemachine coding
Fonts	Standard fonts in Chinese,English,numbers,traditional characters,etc.
File Formats	BMP/DXF/HPGL/JPEG/PLT
Barcodes	CODE39,CODE128,CODE126,QRCode,Datamatrix(optional)
Power Supply	220V/50HZ
Maximum Power Consumption	400W
MachineNet Weight	Split machine:25kg,Integrated machine:17kg:Flying bracket part:22kg
Dimensions	Mainbodyof thesplit machine:465X220X332mm Integrated machine:650X195X265mm Opticalpath section of thesplit machine:625X102X110mm
Environmental Requirements	Extemaltemperature0℃-45℃;Humidity≤95%;Non-condensing:Novibration

Maintenance Free Fiber Laser Marking Machine Eco Friendly Metal Engraving Equipment

Our Services

1. Free Pre-Sales Consultation

Quick Response: We provide pre-sales consultation within 12 hours to address any technical support needs you may have.
Solution Design: Tailored advanced solutions for all distributors and users.

2. Services During Sales

Quality Assurance: All machines undergo strict quality control checks and testing before shipment.
User-Friendly Documentation: Easy-to-understand manuals and operating guides to ensure smooth usage of the equipment.

3. After-Sales Service

Free Video Training: Comprehensive free video training to help you get started quickly.
Technical Support: Our technicians provide support via English, video calls, and remote control.

4. Special Design and Customization

Personalized Service: We are happy to meet your special requirements through innovative design. Whether you need customized machines or OEM orders, please feel free to contact us.
